COMPUTE CARD BLKCD1C64GK |
BLKCD1C64GK |
Beschrijving
Intel BLKCD1C64GK. Frequentie van processor: 1,1 MHz, Processorfabrikant: Intel, Processormodel: N3450. Maximum intern geheugen: 4 GB, Intern geheugentype: LPDDR3, Kloksnelheid geheugen: 1866 MHz. Wi-Fi-standaarden: Wi-Fi 5 (802.11ac), HDMI versie: 1.4b. On-board graphics adapter model: Intel® HD Graphics 500. DC voltage input: 12 V
Specificaties
| Processor | |
|---|---|
| Processorfamilie | Intel® Celeron® N |
| Maximale turbofrequentie van processor | 2,2 GHz |
| Processormodel | N3450 |
| Frequentie van processor | 1,1 MHz |
| Processorcache | 2048 KB |
| Processor socket | BGA 1296 |
| Processor lithografie | 14 nm |
| Thermal Design Power (TDP) | 6 W |
| Aantal processorkernen | 4 |
| Processor aantal threads | 4 |
| 64-bit computing | Ja |
| CPU configuratie (max) | 1 |
| Processorfabrikant | Intel |
| ECC ondersteund door processor | Nee |
| Geheugen | |
| Interne opslagcapaciteit | 64 GB |
| RAM-capaciteit | 4000 MB |
| eMMC capaciteit | 64 GB |
| Maximum intern geheugen | 4 GB |
| Intern geheugentype | LPDDR3 |
| Kloksnelheid geheugen | 1866 MHz |
| Geheugen kanaal | Dubbelkanaals |
| ECC | Nee |
| Ingebouwde opslagcapaciteit | 65536 MB |
| Ondersteunde geheugen types | LPDDR3-SDRAM |
| Poorten & interfaces | |
| HDMI versie | 1.4b |
| Aantal HDMI-poorten | 1 |
| Wifi | Ja |
| Wi-Fi-standaarden | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Nee |
| Bluetooth | Ja |
| Grafische uitvoer | DisplayPort 1.2 and HDMI 1.4b via DDI |
| Kenmerken | |
| Lage halogeen opties beschikbaar | Nee |
| ARK ID | 121220 |
| DC voltage input | 12 V |
| Intel® Virtualization Technology (Intel® VT) | VT-x |
| Intel® High Definition Audio (Intel® HD Audio) | Ja |
| Intel® Trusted Execution Technology | Nee |
| Code geharmoniseerd systeem (HS) | 8471500150 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Intel® Virtualization Technology (VT-x) | Ja |
| Status | Discontinued |
| Intel® vPro™ Platform Eligibility | Nee |
| Grafisch | |
| Ingebouwde grafische adapter | Ja |
| Aantal displays ondersteund | 2 |
| On-board graphics adapter model | Intel® HD Graphics 500 |
| Energie | |
| DC voltage input | 12 V |
| Gewicht en omvang | |
| Afmetingen bord | 94 x 55 mm |
| Hoogte | 5 mm |
| Gewicht | 44,5 g |
| Technische details | |
| ARK ID | 121220 |
| Inhoud van de verpakking | |
| Processor inbegrepen | Intel® Celeron® Processor N3450 (2M Cache, up to 2.2 GHz) |
| Overige specificaties | |
| Processorfamilie | Intel® Celeron® N |
| ARK ID | 121220 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Status | Discontinued |
| Ondersteunde geheugen types | LPDDR3-SDRAM |
| Processor inbegrepen | Intel® Celeron® Processor N3450 (2M Cache, up to 2.2 GHz) |
| Grafische uitvoer | DisplayPort 1.2 and HDMI 1.4b via DDI |
| Lanceringsdatum | Q3'17 |
| Design | |
| Productserie | Intel® Compute Card with Intel® Celeron® Processors |
| Productfamilie | Intel® Compute Cards |
| Processor speciale functies | |
| Intel® Virtualization Technology (Intel® VT) | VT-x |
| Intel® High Definition Audio (Intel® HD Audio) | Ja |
| Intel® Trusted Execution Technology | Nee |
| Intel® Virtualization Technology (VT-x) | Ja |
| Intel® vPro™ Platform Eligibility | Nee |
| Intel® Remote Wake Technology (Intel® RWT) | Ja |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 8471500150 |
